SFS-GM-02B SunRack Ground Screw Mounting System 2017-05-05

SFS-GM-02B SunRack solar ground screws mounting structure type B is widely applied in the panel array of 3 rows,4 rows or larger rows using ground screws to install solar panels in a quite quick and economic way.

SFS-GM-02B SunRack Ground Screw Mounting System

Specification
Installation Site: Open ground
Panel Dimension: Any Size
Panel Type: Framed or frameless panel
Structural materials: aluminum, Q235
Survival wind speed: Up to 60m / s
Design snow pressure: Up to 1.4KN / m2
Component direction: Vertical or Landscape
Tilt angle: Customized
Design Standards: CE&AS / NZS 1170
Life: 10 years on aluminum material,5 years on Q235 steel material

Solar Ground Mount

Features

1. Increased distance between foundation supports to reduce material cost
2. Partially pre-assembled supply mounting structures facilitating for the quick installation

3. 100% high grade aluminum alloy racking with galvanized steel ground screw foundation
